Issue 4.3.C
IP Director Version 4.3 – User Manual – Part 2 – Logging and Browsing
EVS Broadcast Equipment
22
1.6.2 FIELDS IN THE CREATE A NEW LOG WINDOW
The following table describes the fields available in the Create a
New Log window:
Field Description
Level Rating A rating can be given to an event
from no stars to ***.
Description To add alphanumeric free text from
the keyboard.
Keyword Up to 10 keywords can be added per
event, to enter click on a keyword
from any open grid, each mouse
click adds a keyword, to deselect a
keyword, click on it again.
Comment This feature makes the log entry just
a comment entered on the log. This
type of log entry will be displayed
with a different colour in the log
sheet.
1.6.3 HOW TO ADD KEYWORDS SPECIFICALLY TO A
LOG ENTRY
To add data to log entries effectively, it is best practice to add
keywords using the relevant keyword grids. These are usually
best prepared in advance of the logging session although they
could be produced and/or modified at any time. As many keyword
grids as required can be used with a log.
You can add a keyword:
• to a new log element from the Create a New Log window
• to an existing log element from the Edit Log window
To add a keyword individually to a new or existing log element in
a log sheet, proceed as follows:
1. The Create a New Log window or Edit Log window is
opened in the IP Logger.
2. Select either Keywords > Keyword Grid or Keywords >
Dictionary from the Application bar.
3. In the Create or Edit a New Log window, select the
Keywords field:
