Issue 4.3.C
IP Director Version 4.3 – User Manual – Part 2 – Logging and Browsing
EVS Broadcast Equipment
18
1.4.9 HOW TO PRINT A LOG SHEET
To print a Log sheet, proceed as follows:
1. Load the log sheet via the File > Open Log Sheet menu
2. Open the Print Log Sheet window via the File > Print
menu
3. Define the print options.
For more information on the Print options, refer to the
section 1.4.10 ‘Print Log Sheet Window’, on page 18.
4 Se
lect the Print button.
The log sheet is printed on the default printer.
1.4.10 PRINT LOG SHEET WINDOW
The Print Log Sheet window is called from the File > Print menu.
It makes it possible to define layout and print settings to specify
how the log sheet should be printed.
The log sheet table is not automatically adapted for the printout.
The printout reflects what is displayed on the screen. This
implies the following:
• The column width may have to be adapted on the screen.
• The column position may have to be modified by drag-and-
dropping the column heading to the requested position in the
table.
• The columns which are not requested in the printout should
be hidden via the Tools > Organize menu
• If the value in a cell is displayed on two lines, only the first
line will be printed. The column width should be adapted to
have only one line per record.
The following table describes the various print settings available:
Option Description Default
Layout Properties
Log sheet
fields
repeated
for every
log
When this radio button is selected,
the fields specified in the log sheet
header are repeated in each log
record.
This setting excludes the second
radio button
Selected
Log sheet When this radio button is selected, Not
