IP Director Version 4.3 – User Manual – Part 2: Logging and Browsing
EVS Broadcast Equipment
Issue 4.3.C
97
Note
Thumbnails can be created automatically when there is
an XFile designated within the thumbnails configuration
in the Remote Installer application of IP Director. Refer
to the Technical Reference manual for further details.
Thumbnails can be created manually from the Control
Panel and from the Database Explorer. Refer to the
chapters related to these applications for further
details.
3.6.3 BROWSE OPTIONS
These menu options make it possible to load a clip onto a player
channel, play a clip on a player channel or play the list of clips
displayed in the Database Explorer on a player channel.
They can only be used when a channel is assigned to the
Database Explorer.
These icons become active in the menu when the user is within
the Clip tree or on a given bin in the tree structure
These icons turn orange in the menu when the user the
corresponding option is currently used in the Database Explorer.
BROWSE
When enabled, selecting a clip will go to the first frame of a clip
on the associated channel, but does not play it.
PLAY
When enabled, selecting a clip will go to the first frame of a clip
on the associated channel, and play it.
Note
This mode is not recommended when selecting clips to
play for live transmission as there will be a delay
between the loading of the clip and the play-back.
