Issue 4.3.C
IP Director Version 4.3 – User Manual – Part 2 – Logging and Browsing
EVS Broadcast Equipment
90
The Recorder criterion allows specifying one or more recorders.
The clips that have been created on one of the selected
recorders fulfil the Recorder criterion.
The play-lists that are stored on one of the selected recorders
fulfil the Recorder criterion.
The Recorder drop-down list gives access to the XT server
structure which displays all the recorders on all XT servers of
the XNet network. In the structure, you can perform the following
selections:
• Select an XT server. All the recorders on this XT server are
automatically selected.
• Select one or more recorders on one or more XT servers.
Note
The XT structure displayed in the Recorder field
depends on the View XT Structure setting defined in
the General tab of the Tools > Settings menu.
VALIDITY DATE
The validity date specifies until when the bin rule will be applied.
The clips or play-lists matching the bin rules will no longer be
copied to the bin from the end of the day specified in the Validity
field. When you create the bin rule, the default validity date is
one day.
The validity date is calculated against the current date and time
defined on the XT server. This is displayed in red font on the top
right corner of the IP Director main window.
The last day before the expiration date, the Bin Rule icon,
displayed next to the bin in the tree structure will turn red to
inform the user that the bin rule will expire at the end of the
current day.
