IP Director Version 4.3 – User Manual – Part 2: Logging and Browsing
EVS Broadcast Equipment
Issue 4.3.C
87
T/C
The T/C criterion allows specifying a timecode. The clips that
contain the specified timecode, between its limit IN and limit
OUT, will meet the Timecode criterion. If the limit IN or limit OUT
of the clip corresponds to the specified timecode, the clip will
also fulfil the criterion.
Example
If the timecode specified in the T/C criterion is 05:10:30:00 (5h
10mn 30 sec), the following clips will match the defined criterion:
• Clips having a limit IN equal to 05:10:30:00.
• Clips having a timecode equal to 05:10:30:00 between the
limit IN and limit OUT.
• Clips having a limit OUT equal to 05:10:30:00.
STATUS
The Status criterion allows specifying a transfer status. The clips
that have one of the specified statuses will meet the Status
criterion.
The table below describes the various possible statuses that can
be taken into account in the bin rule:
Icon Description
When this icon is selected, the clips that have
not been subject to any transfer, i.e. not
transferred to a destination target, to XFile, to
CleanEdit nor to AVID, fulfil the Status
criterion.
When this icon is selected, the clips which are
still in the process of being transferred to a
destination target fulfil the Status criterion.
When this icon is selected, the clips which are
still in the process of being sent to an XFile
fulfil the Status criterion.
When this yellow icon is selected, the clips
which are still in the process of being sent to
an XStore platform (running a CleanEdit
application) fulfil the Status criterion.
