Installation Sheet

ASSEMBLY & INSTALLATION INSTRUCTIONS
Trim Kit for Evo Affinity 30G
Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA
Phone [phone] | Fax [phone] | www.evoamerica.com | [e-mail]
8
Top Pan (Front Edge)
Center Panel (Front Edge)
End Cap
Support Beam (Outside Edge)
Fasten Support Beam and
Center Panel to End Cap using
1/4” - 20 x 1/2” SS Phillips Head
Screw with Nyloc Nut.
STEP 2: Locate Support Beam and Center Panel as shown, and fasten in place with two
(2) 1/4” - 20 x 1/2” SS Phillips Head Screws with Nyloc Nuts.
STEP 3: Repeat same process for opposite side.
TRIM KIT ASSEMBLY & INSTALLATION
Support Beam installs to inside.
