Datasheet

Everlight Electronics Co., Ltd. http://www.everlight.com Rev.2 Page: 3 of 10
Device No. : DSE-0001426 Prepared date:07-May -2009 Prepared by: Huang yongxin
17-21/G6C-AP1Q1B/3T
Absolute Maximum Ratings (Ta=25℃)
Parameter Symbol Rating Unit
Reverse Voltage V
R
5 V
Forward Current I
F
25 mA
Peak Forward Current
(Duty 1/10 @1KHz)
I
FP
60 mA
Power Dissipation P
d
60 mW
ElectrostaticDischarge
(HBM)
ESD 2000 V
Operating Temperature Topr -40 ~ +85 ℃
Storage Temperature Tstg -40 ~ +90 ℃
Soldering Temperature Tsol
Reflow Soldering: 260 ℃ for 10 sec
Hand Soldering: 350℃ for 3 sec
Electro-Optical Characteristics (Ta=25℃)
Parameter Symbol Min. Typ. Max. Unit Condition
Luminous Intensity
I
v
45
----- 90
mcd
Viewing Angle 2θ
1/2
---- 140 ---- deg
Peak Wavelength λ
p
---- 575 ---- nm
Dominant Wavelength
λ
d
569.5 ---- 577.5
nm
Spectrum Radiation
Bandwidth
△λ
---- 20 ----
nm
Forward Voltage V
F
1.75 ---- 2.35
V
I
F
=20mA
Reverse Current I
R
---- ---- 10 μA
V
R
=5V
Notes:
1.Tolerance of Luminous Intensity ±11%
2.Tolerance of Dominant Wavelength ±1nm
3.Tolerance of Forward Voltage ±0.1V
