7 PRINT READINGS

7.1 Printing using a serial printer

Connect the CyberScan DO 1500 bench meter to the serial printer via RS232C cable (refer to the list of

accessories). The configuration of the RS232C port is as shown below.

Pin Number Description

1 -

2 Transmit Data

3 Receive Data

4 DSR (Data Send Ready)

5 GND (Ground)

6 -

7 -

8 RTS (Request to Send)

9 -

7.2 Setting up the Printer

If the printer has a 25-pin connector, a 25-pin to 9-pin converter will have to be used. Use the following

configuration:

Pin of Meter Pin Number of Printer

2 (TXD) 3 (RXD)

4 (DSR) 20 (DTR)

5 (GND) 7 (GND)

7.3 Connecting the Cable to the Computer

a) If the computer has a 9-pin connector, insert the cable (EC-CA01M09F09) provided into the socket of the

computer, taking note of the gender of the two connectors.

b) If the computer has a 25-pin connector, use a 9-pin to 25-pin, male/ female converter with 9 pins and 25

holes for connection. This converter can be obtained from any computer store.
