19
12. REPLACEMENTS AND ACCESSORIES
Part number Ordering Code
Item Description
Eutech
Instruments
Oakton
Instruments
PC 700 with pH electrode (ECFC7252101B / 59001-
70), conductivity/temp electrode (CONSEN9501D /
35608-74), integral stand,100/240 VAC
ECPC70043S
01X543601
35413-00
PC 700 with integral stand, 100/240 VAC - 35413-20
Plastic, Gel-filled, Double-junction pH electrode ECFC7252201B 35641-51
Plastic, Gel-filled, Single-junction pH electrode ECFC7252101B 59001-70
Replacement conductivity/temp electrode, k = 1.0 CONSEN9501D 35608-74
Epoxy/platinum conductivity/temp electrode, k = 0.1 - 35608-72
Glass/platinum conductivity/temp electrode, k = 1.0 - 35608-76
Epoxy/platinum conductivity/temp electrode, k = 10.0 - 35608-78
SMPS, 100/240 VAC, 9V, 6W power adapter 60X030130 35615-07
10 μS, (20) x 20mL Sachets ECCON10BS 35653-09
84 µS, 480 mL bottle* ECCON84BT 00653-16
447 μS, 480 mL bottle ECCON447BS 00653-47
500 μS, 480 mL bottle ECCON500BT -
1413 μS, 480 mL bottle* ECCON1413BT 00653-18
1413 μS, (20) x 20mL Sachets* ECCON1413BS 35653-11
2764 μS, 480 mL bottle ECCON2764BT 00653-20
2764 μS, (20) x 20mL Sachets ECCON2764BS 35653-12
5.0 mS, 480 mL bottle ECCON5000BT -
12.88 mS, 480 mL bottle* ECCON1288BT 00606-10
15 mS, (20) x 20mL Sachets ECCON15000BS 35653-13
111.8 mS, 480 mL bottle* ECCON1118BT -
*Automatic Calibration Standard Value at 25 ºC
