User Guide

Cadmium Electrode Instruction Manual
20
SPECIFICATIONS
Concentration Range: 1.0X10
-1
M to 1.0X10
-7
M (11,200 to 0.01 ppm)
pH Range: 2 to 12
Temperature Range: 0
o
-80
o
C
Resistance: <1 Mohm
Reproducibility: +/- 2%
Samples: Aqueous solutions only; no organic solvents
Size: 110 mm length; 12 mm diameter; 1 m cable length
Storage: Store in cadmium solution
ORDERING INFORMATION
CODE/NO. DESCRIPTION
EC-CD-03 Cadmium Ion Combination Electrode, epoxy body
EC-ISA-CD1-BT Ionic Strength Adjuster (ISA), 5M NaNO
3
EC-MIS-PP Polishing Paper for the Cadmium Ion Electrodes
