Instruction Manual αlpha CON 2000
37
Mechanical Specifications
Dimensions 144 x 144 x 111.5 mm (5.67 x 5.67 x 4.39 inch)
Weight 950 g
Material PBT
Insulation NEMA 4X, IP 65
8.3 Specifications for panel mount version
Electrical Data and Connections
Signal Output Two 0/4 to 20 mA outputs for conductivity and
temperature, galvanically isolated.
Load
Max. 600
Conductivity input Screw terminal
Connection terminal 5-pin, 9-pin, and 19-pin terminal blocks
Mechanical Specifications
Dimensions 175 x 96 x 96 mm (6.89 x 3.78 x 3.78 inch)
Weight 700 g
Material ABS
Insulation IP 54 (front) / IP 40 (housing)
