Set the desired address via the UP or DOWN buttons.
Controlling:
After having addressed the LED MAT-Bar 4X64 RGB DMX, you may now start operating it via your lighting
controller.
Note:
I
t’s necessary to insert the XLR termination plug (with 120 Ohm) in the last lighting in the link in order to
ensure proper transmission on the DMX data link.
DMX-protocol
Channel 1
Value: Function:
001 – 009 Off
010 - 255 Red
Channel 2
Value: Function:
001 – 009 Off
010 - 255 Green
Channel 3
Value: Function:
001 – 009 Off
010 - 255 Blue
Channel 4
Value: Function:
001 - 255 LED Chaser from left to right
Channel 5
Value: Function:
001 - 255 LED Chaser from up to down
Channel 6 – AUTO Mode, Internal Programs, Sound Control
Value: Function:
001 – 005 No function
006 – 022 Program 1
023 – 039 Program 2
040 – 056 Program 3
057 – 073 Program 4
074 – 090 Program 5
091 – 107 Program 6
108 – 124 Program 7
125 – 141 Program 8
142 – 158 Program 9
159 – 175 Program 10
176 – 192 Program 11
193 – 209 Program 12
210 – 226 Program 13
227 – 249 Program 14
250 – 255 Sound Control
