Instruction manual

!
WARNING
Read and follow these instructions carefully before installing and
using this appliance.
SAVE THESE INSTRUCTIONS
!
WARNING
• DO NOT – operate this appliance before reading this instruction manual.
• DO NOT – place articles on or against this appliance.
• DO NOT – store chemicals, flammable materials or spray aerosols near this
appliance
• DO NOT – operate with panels, covers or guards removed from this appliance.
• DO NOT – enclose this appliance
• DO NOT – modify this applicance
• ALWAYS SUPERVISE YOUNG CHILDREN NEAR THE APPLIANCE.
NATURAL PROPANE
MODEL TYPE Inbuilt Inbuilt
GAS INPUT
HIGH 38.0 MJ/h 38.0 MJ/h
LOW 20.0 MJ/h 19.0 MJ/h
HEAT OUTPUT
HIGH 9.5 kW 9.5 kW
LOW 4.3 kW 4.3 kW
Efficiency 86.5 % 86.5 %
Injector Size Front Ø 2.15 mm Ø 1.25 mm
Injector Size Rear Ø 2.60 mm Ø 1.65 mm
Test Point Pressure
High 0.65 kPa 1.55 kPa
Low 0.16 kPa 0.40 kPa
A.G.A Approval
No to Code AS4553 7494 7494
Electrical Conform to AS3100 240V 50 Hz 106 Watts Max
Air Pressure Switch Cleveland NSZ Series
Cut in Pressure 130 Pa
Cut out Pressure 120 Pa
Electrical Connection Standard Flex. 2 m, 3 pin plug
GAS TYPE Manufacturer
Safety Warnings
The guard in the glass door is fitted to this appliance to reduce the
risk of fire or injury from burns and no part of it should be
permanently removed.
For protection of young children or the infirmed, a secondary guard
is required.
NAME PLATE
A. F. Gason Pty Ltd
Blake St, ARARAT
Victoria, Australia 3377
P.O. Box 268
TO BE INSTALLED BY
AN AUTHORISED
PERSON IN
ACCORDANCE WITH
GAS INSTALLATION
INSTRUCTIONS
PROVIDED WITH THIS
APPLIANCE.
Derwent High Efficiency Gas Log Fire
3
