4.5.5 Knob Set Navigation Keys
Since a knob set may have more parameters than knobs, the PAGE W and
PAGE X keys scroll among them.
Figure 4-12 Knob Set navigation keys
PAGE W
Press the PAGE W key to scroll to the previous page. When on the first page,
pressing PAGE W key does nothing. The PAGE W key lights yellow when there is
a previous page to go to.
PAGE X
Press the PAGE X key to scroll to the next page. When on the last page, pressing
the PAGE X key does nothing. The PAGE X key lights yellow when there is a next
page to go to.
Configuration Pages (CFG)
Many knob sets have a configuration page to set up that knob set. The configu-
ration page for the Inserts knob set, for example, is used to assign plug-ins to a
track. The configuration page for the Aux knob set assigns aux sends to a track.
Some applications can configure presets for plugins and EQs.
Press the PAGE W + PAGE X keys simultaneously to display a knob set’s config-
uration page, if it has one. When on the configuration page, both the PAGE
W
and PAGE X keys light.
NOTE: Configuration pages work only in channel mode.
SEL
ON
BACK
TOP
CFG
PAGE
CFG
PAGE
SOLO
ON
