User guide

AUDIO | VIDEO MEDIA CONTROLLER
USER GUIDE
SURFACE CONTROLS
36
EQ
Press the EQ key to display the EQ knob set to configure equalization controls
and filters. This automatically toggles the MC into channel mode and shows four
EQ bands on eight knobs.
AUX
Press the AUX key to display the Aux knob set to control auxiliary sends. In normal
mode, the first aux send is displayed. In normal mode, press the PAGE X key to
advance to the second aux send. In channel mode, up to eight aux sends can be
shown at once.
PAN
Press the PAN key to display the Pan knob set to configure left/right or surround
panning. In normal mode, the left/right pan control is typically displayed. In
channel mode, the first page of eight pan knobs is shown.
INPUT
Press the INPUT key to display the Input knob set to configure input routing, mic
gains, phantom power, and other application-specific parameters.
DYN
Press the DYN key to display the Dynamics knob set to configure compressors,
limiters, expanders, and gates.
GROUP
Press the GROUP key to display the Group knob set to configure group bus routing
or control group (VCA) membership.
MIX
Press the MIX key to display the Mix knob set to configure output routing.
4.5.4 Dual-Function Knobs
Some knobs have two functions that are toggled by pressing the knob’s SEL key
(i.e., EQ Frequency and Q). The knob name changes in the display to show the
current function. Dual-function knobs are supported in normal mode.
