AUDIO | VIDEO MEDIA CONTROLLER i USER GUIDE Document Revision: F
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER In the interest of continued product development, Euphonix reserves the right to make improvements to this manual and the product it describes at any time, without notice or obligation. MC Control, MC Mix, MC Transport, MC Pro, System 5-MC, and EuCon are trademarks of Euphonix, Inc. ©2008–2009 Euphonix, Inc. All rights reserved worldwide.
Canada This Class B digital apparatus complies with Canadian ICES-003 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER European Union Australia ABN 91 051 557 905 Japan iii
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER IMPORTANT SAFETY INSTRUCTIONS The lighting flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to persons.
13) Unplug this apparatus during lightning storms or when unused for long periods of time. 14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
vi
List of Figures ........................................................................................................ ix Chapter 1: Introduction to the Artist Media Controller................................... 11 Chapter 2: Setup and Installation ..................................................................... 13 2.1 Setting Up the MC Mix ................................................................ 13 2.1.1 Elevating the MC Mix ..................................................... 13 2.1.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER Chapter 5: 4.5 Knobs ........................................................................................ 33 4.5.1 Basic Knob Use.............................................................. 33 4.5.2 Knob Modes .................................................................. 34 4.5.3 Knob Set Selector Keys .................................................. 35 4.5.4 Dual-Function Knobs...................................................... 36 4.5.
1-1 Artist Series media controllers ...................................................................... 11 2-1 Foldout leg (left); riser bracket (right) ........................................................... 13 2-2 Removing side panels (left); removing riser brackets .................................... 14 2-3 Removing screws from the bottom panel ....................................................... 15 2-4 Removing connecting part and side panel ..........................................
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER LIST OF FIGURES x 4-11 Knob Selector keys ....................................................................................... 35 4-12 Knob Set navigation keys .............................................................................. 37 5-1 Selecting EuControl Settings from the taskbar .............................................. 39 5-2 Surfaces tab .................................................................................................
Chapter 1: Introduction to the Artist Media Controller The MC Control, MC Mix, and MC Transport comprise the Artist Series family of media controllers. They use a 100 Mbs Ethernet EuCon connection to control audio/video applications running on a workstation computer. EuCon is a highspeed communication protocol and enables control of virtually every application feature. USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER Each Artist media controller can run as a standalone device.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER Conventions Used in this User Guide The User Guide refers to all functions labeled on the MC Mix surface and rear panel with all caps in bold type (i.e., NUDGE X, PAN, SEL, SOLO). The Shift key is used in conjunction with other keys to access secondary functions labeled in blue above the primary function. Two Shift keys are located at the MC Mix’s bottom-left and -right.
Chapter 2: Setup and Installation Euphonix is dedicated to making your MC Mix experience enjoyable and troublefree so we will periodically update the following software and documentation: • EuControl: This software runs your MC Mix and communicates to your audio/video application. Always download the new version if prompted to do so when you launch EuControl. • MC Mix User Guide (PDF): This is the complete user guide for your MC Mix and the document you are currently reading.
AUDIO | VIDEO MEDIA CONTROLLER USER GUIDE Two larger, detached riser brackets elevate and angle the unit more than the foldout legs. Use moderate force to snap them into the bottom panel as shown in Figure 2-1. To remove the riser brackets: 1. Slide the side panels off (Figure 2-2 left). Figure 2-2 Removing side panels (left); removing riser brackets 14 2. Press the tabs to release the riser brackets (Figure 2-2 right). 3. Lift the riser bracket out of the MC Mix to remove SETUP AND INSTALLATION 2.1.
To join two MC Mixes (or an MC Mix and MC Control): 1. On one of the MC Mixes, use a #2 Phillips screwdriver to remove the two silver screws (Figure 2-3). The screws may be tight, so you may have to use some force. USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER Figure 2-3 Removing screws from the bottom panel 2. Lift the black plastic connecting part and side panel up and out of the MC Mix (Figure 2-4). 15 3.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 2.2 Installation 1. If you downloaded the latest software from the web, double-click the installer. Otherwise, insert the installation CD into your Macintosh. NOTE: Be sure to eject the installation CD in your Mac if you downloaded the latest software from the web. 2. Follow the instructions to install the software. If prompted to download the most current version of EuControl, follow the onscreen instructions.
6. Plug one end of the Ethernet crossover cable into the Ethernet jack (labeled with ) on the rear panel of the MC Mix (Figure 2-8). USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER o Euc n Ethernet cable Figure 2-8 Ethernet cable and rear panel jack 7. Plug the other end of the Ethernet crossover cable into an open Ethernet jack on your computer, router, or Ethernet switch (Figure 2-9). An Ethernet router or switch is required to connect additional MC Mix units or to a local area network.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 9. Press and release the POWER switch on your MC Mix. Look at the top-right of your screen and wait up to 60 seconds. A green icon in the menu bar indicates correct installation. If you did not see the green icon: • See My Surfaces on page 40 and add the MC Mix manually. • Shut down the MC Mix and the Mac and repeat steps 8 and 9.
Connecting a Footswitch The MC Mix has a ¼-in FOOTSWITCH input on the rear panel. The footswitch can be used to punch in and out of recording. Plug the footswitch in before powering on the MC Mix. See page 47 for details.
Chapter 3: Common Tasks If you completed the steps in Chapter 2: Setup and Installation, you are ready to start learning about your MC Mix. We recommend performing these simple tutorials of common tasks in the order presented. Fader Strip USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 1. Press the MC Mix’s strip 1 fader SEL key (Figure 3-1). The corresponding track is selected in your application. 2. Move the MC Mix’s strip 1 fader up and down.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 4. Press the NUDGE X key to move all eight tracks over one strip (Figure 3-2). If tracks 1–8 were assigned to strips 1–8, tracks 2–9 are now assigned to strips 1–8. SEL MIXER CLOSE NUDGE ON SOLO ON PLAY REC NUDGE HOME END BANK BANK Figure 3-2 NUDGE and BANK keys 5. Press the HOME key (Figure 3-2) to restore tracks 1–8 to strips 1–8.
Inserts 1. Add a plug-in on track 1 of your application. 2. If tracks 1–8 are not assigned to strips 1–8, press the HOME key (Figure 3-2) to restore tracks 1–8 to strips 1–8. 3. Press the MC Mix’s strip 1 fader SEL key (Figure 3-4). USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 4. Press the CHAN key to enter channel mode (Figure 3-4).
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 8. Press the PAGE keys to access more parameters (Figure 3-5). SEL TOP BACK CFG ON CFG SOLO PAGE ON PAGE Figure 3-5 BACK and PAGE keys 9. Press the BACK key to exit that plug-in (Figure 3-5). 10. Press the CHAN key to exit channel mode (Figure 3-4).
40 30 20 10 5 0 6 12 SEL Y ASSIGN AUTO REC N SOLO ON 40 30 20 10 5 0 6 12 PREV RTZ SEL Y ASSIGN AUTO ON SOLO REC N ON SEL 40 30 20 10 5 0 6 12 SEL Y ASSIGN AUTO REC N REC PLAY 40 30 20 10 5 0 6 12 60 SEL Y ASSIGN AUTO REC N STOP FF ON SOLO 60 40 30 20 10 5 0 6 12 ON SOLO ON SEL 60 SEL Y ASSIGN AUTO REW NEXT REC N ON SOLO ON SEL 60 40 30 20 10 5 0 6 12 ON SEL 8 8 8 8 Fader strips 60 SEL Y ASSIGN AUTO RE
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 4.1 Power Switch Press and release the POWER switch to turn the MC Mix on/off. 4.2 • All displays shows a Euphonix logo upon power up. • All activity on the displays and LEDs ceases upon power down. Shift Key The Shift key is used in conjunction with other keys to access secondary functions labeled in blue above the primary function. Two Shift keys are located at the MC Mix’s bottom-left and -right.
Fader Strips The MC Mix provides eight fader strips, each with a touch-sensitive fader and a touch-sensitive knob, that control tracks in an audio or video application. 4.3.1 Display Screens At the top of each fader strip is a 128 x 64 pixel Organic Light Emitting Diode (OLED) display that shows the following items: track name/value meter knob name/value knob position 5.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 4.3.2 Fader The fader controls the track assigned to this strip. It is motorized so it reflects changes made in the application, such as automation. It is also touch sensitive, which some applications use when automating.
Transport Controls SOLO ON RTZ PREV SOLO ON REW NEXT SOLO FF ON SOLO ON STOP PLAY REC Figure 4-4 Transport Controls RTZ Press RTZ (Return To Zero) to move to the beginning of the project. PREV Press PREV to move to the previous marker. Not all applications support markers. NEXT Press NEXT to move to the next marker. Not all applications support markers. REW Press REW to rewind. This function varies with the application.
AUDIO | VIDEO MEDIA CONTROLLER USER GUIDE STOP Press STOP to stop all other functions. PLAY Press PLAY to play the project from the current location. REC Press REC begin recording at the current location. All tracks armed for recording are punched into record. 4.3.6 SEL Pressing a fader’s SEL key selects that track in the application and attentions (see Channel Mode on page 34) it on the MC Mix.
4.4 Fader Navigation Controls Scroll through the application’s tracks using the BANK and NUDGE keys. HOME and END are shortcuts to the first and last banks, respectively. USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER SEL MIXER CLOSE NUDGE ON SOLO ON PLAY REC NUDGE HOME END BANK BANK Figure 4-5 Fader navigation controls 4.4.1 BANK and NUDGE The BANK and NUDGE keys change which tracks are assigned to the strips.
AUDIO | VIDEO MEDIA CONTROLLER USER GUIDE BANK W Moves the window one bank (eight tracks) to the left. If strips 1–8 had the bank starting at track 9, they now have the bank starting with track 1. Pressing BANK W again does nothing because the first bank is already shown. BANK X Moves the window one bank (eight tracks) to the right. If strips 1–8 had the bank starting at track 9, they now have the bank starting with track 17. 4.4.2 MIXER and CLOSE Not all applications support these keys.
4.5 Knobs Each fader strip has one touch-sensitive, continuously rotating knob that adjusts parameters such as pan and aux send levels. The knob has a built-in switch allowing it to be pressed from the top. This is called the Knob Top key and is typically used to access sub-menus but also to turn parameters on/off.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 4.5.2 Knob Modes The eight knobs can be in normal or channel modes. Normal Mode Each knob controls the same parameter for every track on the strips. Figure 4-8 Normal mode Channel Mode Channel mode is useful for editing EQs and plug-ins that have many parameters. The eight knobs control up to eight different parameters on a single attentioned track. Press a fader SEL key (page 30) to attention that track.
Knob Set Selector Keys A knob set is an array of knobs used by EuCon applications to control plug-ins, EQs, dynamics, aux sends, etc. One of the eight Knob Set Selector keys is always selected and lit and displays its knob set until another Knob Set Selector key is pressed. When the MC Mix first starts, the PAN knob set is selected by default. INPUT INSERTS DYN EQ GROUP AUX MIX PAN Figure 4-11 Knob Selector keys The Knob Set Selector keys enter the MC Mix menu system.
AUDIO | VIDEO MEDIA CONTROLLER USER GUIDE EQ Press the EQ key to display the EQ knob set to configure equalization controls and filters. This automatically toggles the MC into channel mode and shows four EQ bands on eight knobs. AUX Press the AUX key to display the Aux knob set to control auxiliary sends. In normal mode, the first aux send is displayed. In normal mode, press the PAGE X key to advance to the second aux send. In channel mode, up to eight aux sends can be shown at once.
Knob Set Navigation Keys Since a knob set may have more parameters than knobs, the PAGE W and PAGE X keys scroll among them. SEL TOP BACK CFG ON CFG SOLO PAGE ON PAGE Figure 4-12 Knob Set navigation keys PAGE W Press the PAGE W key to scroll to the previous page. When on the first page, pressing PAGE W key does nothing. The PAGE W key lights yellow when there is a previous page to go to. PAGE X Press the PAGE X key to scroll to the next page.
AUDIO | VIDEO MEDIA CONTROLLER USER GUIDE BACK Press the BACK key once to return to the previous knob set. Press the BACK key repeatedly to back out of all sub-menus and display the top of the current knob set. TOP Press the TOP key to immediately back out of all sub-menus and display the top of the current knob set. This is equivalent to pressing the BACK key repeatedly. 4.5.6 Knob Sets and Multiple MC Mixes Up to four MC Mixes can be linked to form one large surface.
Chapter 5: EuControl EuControl is launched automatically upon starting your Mac and runs in the background. EuControl is responsible for finding, linking, and communicating with all MC Mixes and MC Controls on the network. EuControl’s configuration tasks are accessed by clicking the green icon on the Mac taskbar and selecting EuControl Settings. USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER Only one instance of EuControl can run on a workstation.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 5.1 Surfaces The Surfaces tab shows all Artist media controllers on your network and those connected to your instance of EuControl. 40 Figure 5-2 Surfaces tab All Surfaces All Surfaces shows all Artist media controllers on the network. An MC Mix shown in light gray is already connected either to your own or another instance of EuControl running on a different workstation. In both cases, it is not selectable.
Add B Click Add B to add the selected All Surfaces entry to My Surfaces. This connects this MC Mix to your instance of EuControl. You can also click and drag an MC Mix from All Surfaces to My Surfaces. Add B is disabled if all Artist media controllers in All Surfaces are connected to any instance of EuControl. USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER Remove Click Remove to remove the selected surface from My Surfaces and make it available to other instances of EuControl.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER fcFollow the instructions in the EuControl dialog box. • The Artist media controllers must be plugged into a working power source. • Do not power off any Artist media controllers during the update or attempt to interrupt the update. • The status for each Artist device being updated is displayed on that device as well as in the EuControl dialog box.
Workstations The MC Mix can control applications running on a second computer, referred to in this guide as a workstation. The Workstations tab establishes the list of workstations that the WORKSTATION key cycles through. Any workstation running EuCon software can be in this list, including those controlled by the System 5-MC, MC Pro, and MC Control. 43 Figure 5-3 Workstations tab All Workstations All Workstations lists all EuCon-enabled workstations on the network.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER It is possible to put a workstation in the My Workstations list that is already attached to another instance of EuControl running on another computer. It cannot be attached here until it is unattached from the other instance of EuControl. This was done to allow multiple users to share workstations without having to frequently edit their My Workstation list.
5.3 General This tab controls how the MC Mix and application software work together. USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 45 Figure 5-4 General tab General Preferences Workstation tracks knob set changes The workstation is aware of which knobset is selected and displays appropriate controls. Open plug-ins on workstation when editing When a plug-in knobset is selected on the MC Mix, the workstation opens the plug-in’s window.
AUDIO | VIDEO MEDIA CONTROLLER USER GUIDE Auto-bank to selected track Selecting a track in the application causes the MC Mix to display the bank containing that track. This keeps the selected track assigned to the surface. Display track numbers on surface The track number is included with the track name in the channel display. 5.3.2 Solo Mode Not all applications support Solo mode. Those that support it behave as follows. Solo in place Mutes all tracks except solo track.
AUDIO | VIDEO MEDIA CONTROLLER Preferences USER GUIDE 5.4 Figure 5-5 Preferences tab 5.4.1 MC Mix and MC Transport display screen dim time 47 Drag the slider to set the amount of inactive time before the MC Mix and MC Transport (if included) display screens dims to half intensity. Footswitch The footswitch punches in and out of recording. It is useful when recording and getting ready to play an instrument.
AUDIO | VIDEO MEDIA CONTROLLER USER GUIDE Operation This category selects what happens when the footswitch is pressed. Choose the option that best suits your application. Record | Record: Pressing the footswitch presses the RECORD button, which punches in to record. Releasing the footswitch does nothing. Pressing the footswitch again also presses the RECORD button, which punches out. Record | Play: Pressing the footswitch the first time presses the RECORD button, which punches in.
AUDIO | VIDEO MEDIA CONTROLLER USER GUIDE Assign Figure 5-6 Assign tab 49 This tab manages how tracks are assigned to the MC Mix’s strips. By default, tracks are automatically assigned in banks of eight. NOTE: When a project is reopened, the first eight tracks are assigned to the strips. Click in the Assigned To column to pop up a menu with the following options: • auto assigned: Tracks are assigned automatically in response to the Bank and Nudge buttons.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 5.5.1 Display application’s track numbers Select this checkbox to display the track number in addition to the name. NOTE: Not all applications support track number display. 5.5.2 Lock to application This feature allows the transport controls and/or the entire surface to stay locked to the application listed at the top-left of the dialog (Logic Pro in Figure 5-6), even when that application is not top-most.
AUDIO | VIDEO MEDIA CONTROLLER Layouts USER GUIDE 5.6 Figure 5-7 Layouts tab 51 The tracks assigned to the MC Mix strips can be saved as a Layout. A Layout is created from the current strip assignments and can receive a name. It can then be recalled at a later time. 5.6.1 Recall Highlight a name in the Name column and click Recall to recall that Layout. 5.6.2 Store Click Store to store the MC Mix’s current track assignments as a new Layout.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER EuControl 52 5.7 Soft Keys The Soft Keys tab is relevant only for the MC Control. See the MC Control User Guide for details.
Appendix A: Setting the IP Address Most MC Mix users will never have to set a static Internet Protocol (IP) address but in the rare cases that require it, the MC Mix does allow for it. Normally the MC Mix uses Dynamic Host Configuration Protocol (DHCP) to obtain its IP address, typically from a router. The MC Mix will revert to link-local addressing to generate an IP address if a DHCP server is not found on the network, such as when an MC Mix is connected directly to a computer with an Ethernet cable.
USER GUIDE AUDIO | VIDEO MEDIA CONTROLLER 3. Press the PAGE X key to move the cursor to the next screen, in this case the first field of the IP Address screen (Figure A-2 left). The Knob Top key can also be used to perform the same function as the PAGE X key. Press the PAGE W key to move the cursor back to the previous field or screen to change a parameter to a different value. Figure A-2 IP Address displays 4. Use the knob to set the first field of the IP Address. 5.
