Euphonix MADI Converters Operation Manual MI715/MO705 Converters Features

Ϯ.ϯ MI715/MO705FrontPanel

Thissectiondiscussesbothfrontpanelsandnotestheirfewdifferences.

TrimPotsAccess:Onetrimpotadjussthemaximumanaloginput/outputlevelof

channels1–8in2‐dBstepsbetween+12and+26dBu.

SRConv:This indicatessample‐rateconversionactivityontheauxiliarydigitalinputs.

SampleRateLEDs:TheseLEDsindicatethesampleratetowhichtheconverteriscur‐

rentlylocked.Sampleratesareauto‐sensedbutcanbemanuallyselectedonthe

AM713.Supportedsampleratesare96kHz,88.2kHz,48kHz,44.1kHz,andCustom

ratesfromexternalsources.

SampleRateSourceLEDs:TheseLEDsindicatetheformatoftheSampleRateSource

towhichtheconverteriscurrentlylocked.SampleRateSourcecanbeauto‐sensedor

manuallyselected.Ifanexternalsourceisnotdetected,theMI715revertstoInternal

sync;theMO705mutesitsoutputs.Ifamanuallyselectedsourceisnotpresent,the

SampleRateSourceindicatorblinks.

• AES:SampleRatelockedtoAESInput.

• Word:SampleRatelockedtoWordClockInput.

• Internal(MI715only):SampleRatelockedtoitsowninternalcrystal.

• MADI(MO705only):SampleRatelockedtoMADI.

• Auto:SampleRateSourcehasbeenauto‐sensed.

TheseLEDsappearinthesameorderinwhichsignalsaretestedfortheirpresence.

Thisdetectionprocedureoccurswhentheconvertersarepoweredon.TheSample

Rate(MI715only)andSampleRateSourcecanalsobeselectedmanually.ManualSe‐

lectionButtons:ThebuttonbeloweachSampleRateLEDrowmanuallyselectsthe

samplerate.TheMI715alsoallowsmanualselectionoftheSampleRateSource.

PowerSwitch:On/Offswitch.

NOTE: Therearenouser‐serviceablepartsintheconverters.
