Euphonix MADI Converters Operation Manual

ChapterϮ:MI715/MO705Converters Features

Professionalgradeaudioconversionisaccomplishedutilizing128timesover‐sampled

noise‐shapeddelta‐sigmatechniques.Theanalogtodigitalconversionemploysa

multi‐bitmodulararchitecturewhilethedigitaltoanalogconversionemploysasingle‐

bitmodulatorarchitecture.Low‐jitterreferenceclocksareprovidedutilizingdigital 

PLLtechniqueswithVCXOandVCOoscillators.

Theanaloginputsandoutputscanbecalibratedfromthefrontpanelofeachunit.

AES/EBUandWordClockexternalsyncinputsonbothunitsprovidesynchronization

todigitalsystems.SampleRateSourceandSampleRateareautomaticallysensedby

bothunits.Supportedsa mple ratesinclude44.1,48,88.2,and96kHz.Inaddition,pull‐

upandpull‐downratesforthestandardsamplerates,aswellascustomsamplerates

areavailable.

Ϯ.Ϯ Applications

InadditiontotheirstandarduseinaEuphonixdigitalsystem,theMI715andMO705

canbeusedasstand‐aloneconverters.WhenusedwiththeEuphonixSH612Studio

Hub,thisisapowerfulconversionandMADIroutingsystemthatcanbeusedtointer‐

facebetweenananalogconsoleandanotherwiseall‐digitalfacility(i.e.,TVbroadcast

facility).

NOTE: MADIcablescanbeextendedto50m(164ft),allowingremotelocationofthecon‐

verters.
