Specifications

Euphonix MADI Converters Operation Manual MI715/MO705 Converters Features
14
MO705 Performance Specifications
Sync Sources
AES, word clock, MADI
Sync Outputs
AES thru and word clock out
Sync Detection
Auto or switched
Internal Sample Rate
44.1, 48, 88.2, 96 kHz ±50 ppm
Lock range
fine mode 300 ppm
custom mode
12% varispeed of 44.1 and 48 kHz
Above 50 kHz, varispeed can adjust the nominal sample rate by -12 to +5%
MADI Input
BNC 75 
44.1/48 kHz: 56 channels
88.2/96 kHz: 28 channels. Outputs mapped to channels 1–24, 24-bit signal
path
Audio Outputs
8 analog,16 AES
Analog Outputs (1–8)
Electronically balanced XLR; 200  output impedance
Level for 0 dBFS Adjustable between +12 and +26 dBu in 2-dB steps
Signal-to-Noise Ratio 101 dB (unweighted)
THD 0.0003%
Frequency Response
(1 kHz @ +4 dBu)
0.25 dB 20 Hz – 20 kHz @ 48 kHz
-2.5 dB 20 Hz – 40 kHz @ 96 kHz
CMRR >50 dB 20 Hz – 20 kHz
Crosstalk
 -110 dB @ 1 kHz
 -100 dB 20 Hz – 20 kHz
Group Delay
28.2/F
s
(588 s @ 48 kHz)
AES Outputs (9–24)
AES on XLR, transformer isolated, 110 , 24 bit
User can truncate to 16- or 20-bit per stereo pair
Truncation Type
Dithered or 1
st
order noise-shaped, internally switched
Dither Type TPDF (active only for 16- or 20-bit word length)
Digital Format Pro or Consumer, internally switched
Group Delay
3/F
s
(63 μs @ 48 kHz)
AES (XLR), transformer isolated, 110 
S/PDIF (RCA), 75 
Digital Format professional or consumer (internally switched)
