Specifications

Euphonix MADI Converters Operation Manual MI715/MO705 Converters Features
13
2.7 Specifications
MI715 Performance Specifications
Sync Sources
AES, word clock, internal
Sync Outputs
AES thru and word clock out
Sync Detection
Auto or switched
Internal Sample Rate
44.1, 48, 88.2, 96 kHz ±50 ppm
Lock range
fine mode 300 ppm
custom mode
12% varispeed of 44.1 and 48 kHz
Above 50 kHz, varispeed can adjust the nominal sample rate by -12 to +5%
Audio Inputs
8 analog, 16 AES
Analog Inputs (1–8)
Electronically balanced XLR; 20 k input impedance
Level for 0 dBFS Adjustable between +12 and +26 dBu in 2-dB steps
Signal-to-Noise Ratio 105 dB (unweighted)
THD 0.0005%
Frequency Response
(1 kHz @ +4 dBu)
0.25 dB 20 Hz – 20 kHz @ 48 kHz
-2.5 dB 20 Hz – 40 kHz @ 96 kHz
CMRR >50 dB 20 Hz – 20 kHz
Crosstalk
 -110 dB @ 1 kHz
 -100dB 20 Hz – 20 kHz
Group Delay
41.7/F
s
(869 s @ 48 kHz)
AES Inputs (9-24)
XLR, transformer isolated, 110 , 24-bit Group delay varies with sync frequency
and inputs
MADI Output
BNC 75 
24 channels at all sample rates
Inputs mapped to channels 1–24, 24-bit signal path
