Cross Section of Typical Valve (KTG4V-3S)
Graphical Symbols
KTG4V
KDG4V
Solenoid B Port A Port B
Note: On all models, when solenoid a" is energized, flow is always P" to A".
When solenoid b" is energized, flow is always P" to B". This is in accordance
with the ANSI-B93.9 standard. Solenoid designations a" and b" are identified
on the diagram plate on the side of the valve.
KDG4V-3-33C**N
b
AB
PT
a

KTG4V-3-2B
AB
PT
KTG4V-3-33B
AB
PT


