Specifications

31
KADG4V-3 and KATG4V-3 Installation Dimensions
Metal plug 934939
Cable outside diameter 8,0 to 10,5 (0.31 to 0.41)
Must be used for full EMC protection. See also
warning note on page 18.
Plastic plug 694534
PG11. Cable maximum
outside diameter 11,0
(0.43)
7-pin plug
40,0
(1.6)
16,8 (0.66)
16,8 (0.66)
98,8 (3.89)
238,0 (9.37) without overrides
10,0 (0.4) for plain
manual override
10,0 (0.4) for plain
manual override
61,0 (2.4) for coil removal
14,0 (0.55) for
weather-resistant
manual overrides
14,0 (0.55) for
weather-resistant
manual overrides
24,5
(0.96)
61,0 (2.4) for coil removal
21,75
(0.86)
51,0
(2.0)
∅ 5,6 (0.22) thru.
∅ 9,0 (0.35) c’bore
to depth shown.
4 places
Remove plug for
access to the gain
potentiometer
227,0 (8.9)
LED “Power on”, green
274,0 (10.8) max.
128,0 (5.1)
max.
Do not remove
these plugs.
PG 11 cable gland. Max.
cable diameter 11,0 (0.43),
on 7-pin plug supplied with
valve. Replacement part
numbers shown at left.
3rd angle
projection
24,0
(0.94)
21,75
(0.86)
To bleed air, loosen plug
in end of core tube;
re-tighten after bleeding
is complete.
98,87 (3.89)
KATG4V-3
Dimensions in mm (inches)
7-pin plugs for integral
amplifiers
Metal.............934939
Plastic............694534
(Metal plug must be used
for full EMC protection.)
227,0 (8.9)
48,0
(1.9)
128,0 (5.1)
max.
200,0 (7.9) max.
Additional dimensions
are as shown above.
Remove plug for
access to the gain
potentiometer
Additional dimensions
are as shown below.
25,0
(1.0)
7-pin plug
KADG4V-3
Dimensions in mm (inches)
