Specifications

30
KDG4V-3 and KTG4V-3 Installation Dimensions
16,8 (0.66)
3rd angle
projection
24,0
(0.94)
24.5
(0.96)
21,75
(0.86)
48,00
(1.9)
KDG4V-3
Dimensions in mm (inches)
Plug connector can be repositioned in
90° increments by loosening knurled
nut, turning coil, and re-tightening.
164,0 (6.46) without override
74,0 (2.9)
51.0
(2.0)
35,0
(1.4)
13,0 (0.50) for
plug removal
Seal
51
(2.01)
27
(1.06)
22,5
(0.88)
∅
M3 thread
5,5
(0.22)
1,5
(0.06)
30,5
(1.20)

26,5
(1.04)
27,5
(1.08)
18
(0.71)
DIN 43650 plug connector is not
included with valve and must be
ordered separately. For black plug
marked B, order part 710775. For gray
plug marked A, order part 710776.
Conductor cross-sectional area:
0,5 to 1,5 mm
2
(0.0008 to 0.0023 in
2
)
Cable diameter range:
6 to 10 mm (0.24 to 0.40 in)
To bleed air, loosen plug
in end of core tube;
re-tighten after bleeding
is complete.
74,0 (2.9)
16,8 (0.66)
98,8 (3.89)
238,0 (9.37) without overrides
10,0 (0.4) for plain
manual override
10,0 (0.4) for plain
manual override
61,0 (2.4) for coil removal
14,0 (0.55) for
weather-resistant
manual overrides
14,0 (0.55) for
weather-resistant
manual overrides
24,5
(0.96)
61,0 (2.4) for coil removal
21,75
(0.86)
51,0
(2.0)
35,0
(1.4)
13,0 (0.5)
for plug
removal
∅ 5,6 (0.22) thru.
∅ 9,0 (0.35) c’bore
to depth shown.
4 places
98,87 (3.89)
∅ 5,6 (0.22) thru.
∅ 9,0 (0.35) c’bore
to depth shown. 4 places
Plug connector can be repositioned in
90° increments by loosening knurled
nut, turning coil, and re-tightening.
10,0 (0.4) for plain
manual override
14,0 (0.55) for weather-resistant
manual overrides
61,0 (2.4) for coil removal
Means of connection: screw terminals
KTG4V-3
Dimensions in mm (inches)
Solenoid Plug Connectors
Dimensions in mm (inches)

