Specifications

16
KTG4V-3S with EN427 Feature
bar
210
KTG4V-3S-2B 08N-(V)M-*** *** *(1)-H5-60-EN427
Flow rate
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
.5
20
18
16
14
12
10
8
6
4
2
Current - Amps
0 .2 .4 .6 .8 1.0 1.2 1.4 1.6
USgpm l/min.
70 bar (1015 psi)
5 bar (73 psi)
0
Valve pressure drop
l/min. 0 4 8 12 16 20 24 28 32 36 40
200
180
160
140
120
100
80
60
40
20
2800
2400
2000
1800
1200
800
400
psi
3000
USgpm 0 1 2 3 4 5 6 7 8 9 10
Flow Gain Curve Power Capacity Curve
This valve feature is recommended
for use as a pilot valve with the
Valvistor Slip-in Cartridge Valve.
The spool adjuster is preset at the
factory. Do not adjust. Improper
operation will result.
Spool adjuster (Factory set.
Do not adjust)
189,27 (7.45)
EN427 Performance
P
A
B
T
