KDG4V-3S and KTG4V-3S Frequency Response
For amplitude of "25% maximum stroke
(center to offset) about 50% position and
p (P→A→B→T)=10 bar (145 psi).
12345678
10
20 30 40 50
–9
–6
–3
0
135°
90°
45°
0°
AMPLITUDE – dB
PHASE LAG – degrees
FREQUENCY RESPONSE – Hz
