Appendix
Technical data
Interfaces
DMX512/1990 1 x In
1 x Out (loop output)
Analog control voltages 12 x 0 V to +10 V
RS-232 1 x e.g. for a laptop
Link 1 x to link a number of devices
Functions
Sources of the control signals 1. DMX
2. Analog
3. Stored presets,
individual or simultaneous
Combination of different control
signals
Real-time maximum creation
DMX512/1990 address area Can be set from 1 to 512 for each
channel individually via the display on
the front plate
Auxiliary groups 12, independently of the lighting control
system
Chase Adjustable wait and fade-in times, free
sequence selection, independently of
the lighting control system
Preheat 0% to 30%; can be set independently
for each dimmer channel
Output level limit 30% to 100%; can be set independently
for each dimmer channel
