Dimmer curves Providing stationary lighting
– 32 –
Alex M
030430-150B
Alex_M_E_150C_A5.doc
LG
Logarithmic or voltage
linear,
for 115 V at an output
level of 50%
0
10
20
30
40
50
60
70
80
90
100
1
16
31
46
61
76
91
106
121
136
151
166
181
196
211
226
241
256
Input
Output power (%)
ND
Non-Dim (switching curve)
0
10
20
30
40
50
60
70
80
90
100
1
16
31
46
61
76
91
106
121
136
151
166
181
196
211
226
241
256
Input
Output power (%)
Assigning a dimmer curve individually for each dimmer channel
1 Press [Page] to call menu page 2,
Parameters.
2 Use the knob to move the selection
cursor to the DCU row and to the
desired channel in this row.
3 Press [Edit] and use the knob to set the
desired dimmer curve.*
4 Press [Save] to save the currently
selected dimmer curve (ND for non-dim
on channel 5 in the figure).
Fig. 18: Assigning a dimmer curve
individually
*)
As you turn the knob, four unassigned characteristic curve storage locations (--)
appear between the LG and ND curves.
