Intensity limit Providing stationary lighting

– 30 –

Alex M

030430-150B

Alex_M_E_150C_A5.doc

Setting the same intensity limit for all dimmer channels

Press [Page] to call menu page 2,

Parameters.

2 Use the knob to move the selection

cursor to the ALL input field.

3 You can set the same values here for

all channels for the following:

− Preheat (PRE)

− Intensity limit (LIM)

− Dimmer curve (DCU)

Fig. 17: Setting the same intensity

limit for all channels

4 Turn the knob until ALL LIM appears.

• The currently set limit intensity value is highlighted (90 in the figure).

5 Press [Edit] and use the knob to set the desired limit intensity value.

6 Press [Save] to save the currently selected limit intensity value for all channels.
