Datasheet

Thermal Overcurrent Circuit Breaker 3130
www.e-t-a.de
1815 4
1
The time/current characteristic curve depends on the ambient temperature
prevailing. In order to eliminate nuisance tripping, please multiply the circuit
breaker current ratings by the derating factor shown below. See also section
Technical information.
Ambient °F
temperature °C
-22
-30
-4
-20
+14
-10
+32
0
+73.4
+23
+104
+40
+122
+50
+140
+60
Derating factor 0.8 0.84 0.88 0.92 1 1.08 1.14 1.23
Trip time in seconds
+23 °C
+73.4 °F
+60 °C
+140 °F
-30 °C
-22 °F
… times rated current
Trip time in seconds
+23 °C
+73.4 °F
+60 °C
+140 °F
-30 °C
-22 °F
12468102040
10000
1000
100
10
1
0.1
0.1…2 A
2.5…20 A 1-pole
2.5…16 A 2- and 3-pole
Multipole types: all poles symmetrically loaded.
With single pole overload, thermal tripping will be at
approx. 1.54 x I
N
with 2-pole devices and at
approx. 1.68 x I
N
with 3-pole devices.
12468102040
10000
1000
100
10
1
0.1
… times rated current
This is a metric design and millimeter dimensions take precedence (
mm
)
inch
Installation drawing 3130-F1...
mounting area
When installing the circuit breaker apply pressure on bezel only.
I.2
LINE
I.II.3
10
32
7
25
20
5
8
7
operating area
.984
1.26
.276.276.315
.787
.197
.394
Accessories 3130-F130-...
Typical time/current characteristics
ø4.4
.173
36.5
1.44
41.5
1.63
1.97
.197
.472
.315
1.97
.433
2.17
12
5
50
55
50
ø11
ø8
Splash cover, transparent, for 3-pole version
X
221 258 01 (IP54), comprising bezel Y 306 109 01
and transparent cover Y 306 108 01
All dimensions without tolerances are for reference only. In the interest of improved design,
performance and cost effectiveness the right to make changes in these specifications
without notice is reserved.Product markings may not be exactly as the ordering codes.
Errors and omissions excepted.
