8489 Non-Paired - Audio, Control and Instrumentation Cable
Operating Temperature Range -20°C To +60°C
UL Temperature Rating 60°C (UL AWM Style 2598)
Bulk Cable Weight 44.1 lbs/1000 ft.
Max. Recommended Pulling Tension 83 lbs.
Min. Bend Radius (Install) 2.6 in.
APPLICABLE SPECIFICATIONS AND AGENCY COMPLIANCE:
APPLICABLE STANDARDS:
NEC/(UL) Specification CMG
CEC/C(UL) Specification CMG
AWM Specification UL Style 2598 (300 V 60°C)
EU CE Mark (Y/N) Yes
EU RoHS Compliant (Y/N) Yes
EU RoHS Compliance Date (mm/dd/yyyy): 04/01/2005
FLAME TEST:
C(UL) Flame Test FT4
PLENUM/NON-PLENUM:
Plenum (Y/N) N
Plenum Number 88489, 82489
ELECTRICAL CHARACTERISTICS:
Nom. Capacitance Conductor to Conductor @ 1 KHz 26 pF/ft
Nom. Conductor DC Resistance @ 20 Deg. C 6.3 Ohms/1000 ft
Max. Operating Voltage - UL 300 V RMS (UL AWM Style 2598)
Max. Recommended Current 4 Amps per conductor @ 25°C
PUT-UPS AND COLORS:
Item Description Put-Up (ft.) Ship Weight (lbs.) Jacket Color Notes
8489 060100 4 #18 PVC PVC 100 5.1 CHROME
8489 0601000 4 #18 PVC PVC 1000 48 CHROME C
8489 060250 4 #18 PVC PVC 250 12 CHROME
8489 060500 4 #18 PVC PVC 500 24 CHROME C
8489 060U1000 4 #18 PVC PVC U1000 46 CHROME
8489 060U500 4 #18 PVC PVC U500 23.5 CHROME
C = CRATE REEL PUT-UP.
Revision Number: 2 Revision Date: 05-16-2005
Page 2 of
3
