REAR PANEL FEATURES
1. AC Mains Input– Connectthe9'(3m)powercordtoa15A120VACoutlettoprovidepowertotheETA-ECS3.
2. Sequence 1 AC Outlets– ThethreeACoutletsare“Live”whentheSequence1sectionisactivated.Theseoutletsare
recommended for products such as Computers, Modems, Routers, DSP Processors, Cable/SAT, DVD, or CRT TV’s. These outlets
have a special filter circuit that is optimized to reduce interference to your Digital and Analog components. The total maximum
drawforthissequentialsectionis10AandthetotalcurrentdrawfortheETA-ECS3is15A.Note:Itdoesnotharmhighcurrent
audio components to be connected to the Sequential Section 1 digital filter outlets.
3. Sequence 2 AC Outlets– ThetwoACoutletsare“Live”whentheSequence2sectionisactivated.Theseoutletsare
recommendedforAnalogandDigitaltypeproductssuchasAudioReceivers,TapeDecks,Mixers,orVideoEquipment.These
outlets have a special filter circuit that is optimized to reduce interference to your analog type components. The total maximum
drawforthissequentialsectionis10AandthetotalcurrentdrawfortheETA-ECS3is15A.Note:Itdoesnotharmhighcurrent
audio components to be connected to the Sequential Section 2 filter outlets.
4. Sequence 3 AC Outlet–ThesinglehighcurrentnonfilteredACoutletis“Live”whenSequence3sectionisactivated.This
outlet is designed to deliver maximum current to power hungry components like amplifiers and projectors. It does not harm low
power consuming components when connected to the Sequential Section 3 Analog filter outlets. If more high power outlets
are needed or if 15A is not enough current to support your power requirements you can use the 24VDC trigger to activate an
additionalpoweroutletsuchastheETA-20SH.ContactETASystemsforACoutletoptions.
5. XLR Light Socket– A12VDCXLRlightsocketistoprovidepowerfortheoptionalAtlasPowerAP-GNL18light.
6. Light Socket Power Switch– ThisswitchturnstheXLRlightsocketON/OFF.
7. Unswitched AC Outlet– This120VACoutletisalwayslivewhentheETA-ECS3powercordispluggedintoanACMainspower
sourceandvoltageispresent.IfvoltageispresentattheoutletsitwillbedisplayedontheACMainsMeter.Note:TheACMains
power switch or sequencer section does not affect the Unswitched AC Outlets. The Unswitched Outlets are protected by the
surgeprotectioncircuitrybutwillnotbeshutoffbytheEVScircuit.
ETA-ECS3
Power Sequencer & Conditioner
326 5 4 7 1
