User Guide Part 8

Technical Specifications
288
We.R
System User Guide
Up to two years battery’s lifetime
Size and Weight
RF Transmitter size H: 29.2mm (1.15in.), L: 71.9mm (2.83in.), W: 24.6mm (0.97in.)
Weight 25 grams (0.55lbs.) + 15 grams (0.33lbs.) battery
Detector size H: 22.4mm (0.88in.), D: 49.9mm (1.96in.)
Weight 25 grams (0.55lbs.)
Cable length 30cm (11.8in.)
Environment
Storage Ambient Temperature range: -20
o
C +50
o
C (-4
o
F +122
o
F)
Operating Ambient Temperature range with battery: 0
o
C +50
o
C (32
o
F +122
o
F)
RF transmitter humidity: Up to 95% non-condensing
Certification
FCC
IC
Comments
YXG-ES800FL
11061A-ES800FL
(In lab.)
Smoke Detector (SK2) ES800SK2
Communication
Maximum RF range 500m (1640ft.) open air
ECOP bi-directional radio protocol
Modulation and Frequency: DSSS, 2.4GHz
Security
Tamper Alarm when detached from base
Mechanism prevents installation without battery
Buzzer operates even if the Central Control Unit is not functional
