User Guide Part 8

Technical Specifications
286
We.R
™
System User Guide
Operating Ambient Temperature range with battery: -5
o
C – +55
o
C (23
o
F – +131
o
F)
Humidity: Up to 95% non-condensing
Certification
FCC
IC
Comments
Y4I-M801EKF
11061A-ES800KF
Wireless Access Control Tag Reader (TR5) – ES800TR5
Communication
Maximum RF range 500m (1640ft.) open air
ECOP bi-directional radio protocol
Modulation and Frequency: DSSS, 2.4GHz
RFID band: ISO 14443A/MiFare, 106kbps, 13.56MHz
Security
Tamper Alarm – when detached from wall
Data Security – 128-bit AES encryption
Unique electronic serial number
Supports automatic over-the-air software upgrade (RSU) programming and
configuration
Power Consumption
Efficient power consumption to extend the operation period
Three AA-size alkaline batteries (Reader only)
Up to nine months batteries’ lifetime
Size and Weight
Reader – H: 27.6mm (1.09in.), L: 97.8mm (3.85in.), W: 97.8mm (3.85in.)
