User Guide Part 8

Technical Specifications
284
We.R
™
System User Guide
Certification

FCC
IC
Comments
Y4I-M800MGL
11061A-ES800MGL
Indoor Siren (SRN) – ES800SRN
Communication
 Maximum RF range 500m (1640 ft.) open air
 ECOP bi-directional radio protocol
 Modulation and Frequency: DSSS, 2.4GHz
Security
 Tamper Alarm – if removed from back bracket
 Data Security – 128bit AES encryption
 Unique electronic serial number
 Supports automatic over-the-air software upgrade (RSU) programming and
configuration
Power Consumption
 Efficient power consumption to extend the operation period
 Four AA-size alkaline batteries
 Two years batteries’ lifetime
Size and Weight
 H: 39mm (1.54in.), Diameter: 120mm (4.72in.).
 Weight – 150 grams (0.33lbs.) + 100 grams (0.22lbs.) batteries
Environment
 Storage Ambient Temperature range: -20
o
C – +50
o
C (-4
o
F – +122
o
F)
