Door/Window Magnetic Sensor (MGL) – ES800MGL
Communication
 Maximum RF range 500m (1640ft.) open air
 ECOP bi-directional radio protocol
 Modulation and Frequency: DSSS, 2.4GHz
Security
 Data Security – 128-bit AES encryption
 Unique electronic serial number
 Supports automatic over-the-air software upgrade (RSU) programming and
configuration
Power Consumption
 Efficient power consumption to extend the operation period
 One AA-size alkaline battery
 Up to two years battery’s lifetime
Size and Weight
 Detector size – H: 25mm (0.98in.), L: 72mm (2.83in.), W: 30mm (1.18in.)
 Weight – 25 grams (0.55lbs.) + 15 grams (0.33lbs.) battery
 Magnet size – H: 18mm (0.71in.), L: 52mm (2.05in.), W: 24mm (0.94in.)
 Weight – 25 grams (0.55lbs.)
Environment
 Storage Ambient Temperature range: -20
o
C – +50
o
C (-4
o
F – +122
o
F)
 Operating Ambient Temperature range with battery: 0
o
C – +50
o
C (32
o
F – +122
o
F)
 RF transmitter humidity: Up to 95% non-condensing
