User Guide Part 8

Technical Specifications
282
We.R
™
System User Guide
Security
4G DragonFlyEye
™
technology
Tamper Alarm – when unit is tilted
Data Security – 128-bit AES encryption
Unique electronic serial number
Supports automatic over-the-air software upgrade (RSU) programming and
configuration
Temperature compensation for the PIR element
Optional up to 30 Kg (66lb.) pet immune lens
Detecting Range – up to 12m (39.4ft.)
Power Consumption
Efficient power consumption to extend the operation period
Two AA-size alkaline batteries
Three years batteries’ lifetime
Size and Weight
H: 50mm (1.97in.), L: 114mm (4.49in.), W: 60mm (2.36in.)
Weight – 90 grams (0.2lbs.) + 30 grams (0.07lbs.) batteries
Environment
Storage Ambient Temperature range: -20
o
C – +50
o
C (-4
o
F – +122
o
F)
Operating Ambient Temperature range with battery: 0
o
C – +50
o
C (+32
o
F – +122
o
F)
RF transmitter humidity: Up to 95% non-condensing
Certification
FCC
IC
Comments
Y4I-M800PIR
11061A-ES800PIR
