User Guide Part 8

Security Aspects
We.R
™
System User Guide
279
Appendix C Technical Specifications
Central Control Unit (CCU) – ES8000CP
Communication
 Maximum RF range 600m (1968ft.) open air
 ECOP bi-directional radio protocol
 Modulation and Frequency: DSSS, 2.4GHz
 Ethernet and optional GSM/EDGE/2G cloud communication
Security
 Data Security – 128-bit AES encryption
 Unique electronic serial number
 Supports automatic over-the-air software upgrade programming and configuration
Power Consumption
 100-240V
AC
to 5V
DC
Power Adapter/Charger and 3.7V/1.4Ah Li-polymer rechargeable
backup battery (providing up to 5 hours)
 Efficient power consumption to extend the operation period
Size and Weight
 H: 40.8mm (1. 61in.), L: 141mm (5.55in.), W: 74.8mm (2.94in.)
 Weight – 125 grams (0.27lbs.) + 35 grams (0.08lbs.) backup battery
Environment
 Storage Ambient Temperature range: -20
o
C – +60
o
C (-4
o
F – +140
o
F)
 Operating Ambient Temperature range with battery: -5
o
C – +50
o
C (+23
o
F – +122
o
F)
 Humidity: Up to 95% non-condensing
