6. Security Aspects
6.1. Secured Communication between User and Application Server
 Authentication:
 Mobile authentication is performed via email, password and User Code for
the activation of the Mobile Application.
 Password and User codes are encrypted on the mobile handset utilizing
SHA1 algorithm.
 The encrypted value is calculated and sent as identifying credentials.
 The server generates the encrypted value locally, based on stored user
details, and then authenticates the value by comparison.
6.2. Communication Security between CCU and Application Server
 Data is encrypted and secured using SSL between the web/smartphone applications
and the ECS.
 Data is authenticated using a proprietary protocol.
6.3. Communication Security between CCU and sensors
 All communication between the Central Control Unit and the sensors are encrypted
with an AES algorithm, 128 bit and varying keys.
