Maintenance of the We.R™ System
We.R
™
System User Guide
253
5.1.10.3. Installing a New Battery
1. The battery should be installed, as demonstrated in Figure 214 below (the positive () pole
as marked within the device body):
Figure 214: Inserting a Battery into the Transmitter Unit
2. Verify battery polarity match to marking within the unit body.
3. Return the cover onto the base and click it in.
The insertion of battery into the Universal Transmitter triggers a bonding process in which the
Universal Transmitter communicates with the CCU to re-instate it into the CCU peripherals’
inventory.
Note: There is no need to perform “Add Device” process following battery
replacement since the Universal Transmitter is already defined in the
We.R
™
system.
