User Guide Part 8

Maintenance of the We.R™ System
We.R
™
System User Guide
245
Figure 206: Inserting the New KF’s Battery
Note: There is no need to perform “Add Device” process following battery
replacement since the KF is already defined in the We.R
™
system.
5.1.7. Replacing the Tag Reader (TR5) Batteries
For its operation, the Tag Reader needs three (3) 1.5V AA-size Alkaline batteries.
5.1.7.1. Removing the Old Batteries
To replace the old batteries of the Tag Reader, first, there is a need to dismount it from its
install site (the wall).
1. To dismount the Tag Reader, press the wall mounting base's tab at the bottom of the Tag
Reader and slide the body upwards as demonstrated in Figure 207 below.
2. The mounting base (back cover) of the Tag Reader is the batteries’ cover as well and,
therefore, dismounting the Tag Reader also reveals its batteries compartments (three off).
3. Remove the batteries by pressing them slightly towards the negative (–) pole and
extracting them out, one at a time.
