Maintenance of the We.R™ System

244

We.R

™

System User Guide

5.1.6.1. Removing the Old Battery

1. Release the cover of the KF battery compartment by inserting a coin into the slot and

turning the cover a quarter of a circle (90

) counter-clockwise until the two small bumps

face each other as demonstrated in Figure 205 below.

Figure 205: Releasing the KF’s Battery Cover

2. Remove the cover by tapping it upside-down on your palm.

3. Remove the old battery.

5.1.6.2. Installing a New battery

Note: It is advised to release stored charges within the KF electronic circuit

by clicking on any of the front panel keys a few times before the installation

of the new battery.

1. Insert the new battery into the KF’s cavity with its positive () pole facing out/up.

2. Seal the cover by turning it a quarter of a circle (90

) clockwise.
