User Guide Part 8

Maintenance of the We.R™ System
236
We.R
System User Guide
2. Close the inner batteries’ cover and click it back to place.
3. Return the Camera back onto its mounting base.
The insertion of batteries into the Camera triggers a bonding process in which the Camera
communicates with the CCU to re-instate it into the CCU peripherals’ inventory.
Note: There is no need to perform “Add Device” process following batteries
replacement since the Camera is already defined in the We.R
system.
But, replacing the batteries will trigger the Walk Test Mode (see
paragraph 3.6.4.1 above) to ensure proper battery replacement.
5.1.3. Replacing the Motion Detector (PIR) Batteries
For its operation, the Motion Detector needs two (2) 1.5V AA-size Alkaline batteries.
Note: Rattling sounds might be heard during the batteries replacement
process. Nothing to worry about it is the tampering prevention
mechanism.
5.1.3.1. Removing the Old Batteries
To replace the old batteries of the Motion Detector, first, there is a need to dismount it from its
install site (the wall).
1. To dismount the Motion Detector, press the wall mounting base's tab at the bottom of the
Motion Detector and slide it downwards simultaneously as demonstrated in Figure 198
below.
