User Guide Part 8

Maintenance of the We.R™ System
We.R
™
System User Guide
231
5. Maintenance of the We.R
™
System
The We.R
™
system is almost maintenance-free; the only maintenance-oriented activities
required for its continuous operation are:
1. Replacing Batteries – an indication of the need for batteries replacement is provided by
both the We.R
™
Web Application and the We.R
™
Mobile Application utilizing their different
status displays.
2. Cleaning the Smoke Detector’s filter – on a monthly basis, to remove dust that might block
the path to the sensor.
Other than that, there is no other maintenance activity required for proper operation of the
We.R
™
system.
5.1. Replacing Batteries
5.1.1. Replacing the Central Control Unit Backup Battery
For its operation, the Central Control Unit (CCU) needs a special 3.7V
DC
, 1400
mAh
Lithium
Polymer rechargeable battery (Essence P/N MCBT05001) and a Power Adapter.
5.1.1.1. Removing the Old Backup Battery
To remove an old battery from the CCU:
1. Remove the Power Supply from the mains socket and disconnect its cable and mini-USB™
connector from the CCU.
5. Remove the CCU’s back cover, to reveal the battery’s and SIM-card compartment, by
inserting a finger nail between the cover and its frame and lift it as demonstrated in Figure
192 above.
6. Remove the battery by lifting its top-facing edge (note that a special bay is provided for this
purpose) and pulling the battery out of the battery cavity, as demonstrated in Figure 193
below.
