User Guide Part 8

Administration of the We.R™ System
228
We.R
™
System User Guide
Once the Walk-Through feature is enabled:
 Throughout the 30 seconds delay period of an Entry/Exit configured device, the device
configured as Walk-Through will trigger an alarm only if triggered before the device
defined as Entry/Exit.
The detection of the Walk-Through device will be logged in the Recent Events report.
In case of Entry/Exit – if the system is not disarmed within the 30 seconds delay period,
the Walk-Through device will trigger an alarm.
 In case a Walk-Through device is directly triggered (the Entry/Exit device was not
triggered first) – an alarm will immediately be triggered.
 In case the Walk-Through devices is a Camera (IPD) and was triggered following an
Entry/Exit device and the system was disarmed – a security image capturing event will
be logged, however, no security clip will be available for view since eventually no alarm
was triggered.
Common use of the Walk-Through feature – if a Magnetic Sensor (MGL) is installed on the
main-entry door and defined as Entry/Exit, and a Camera (IPD) or Motion Detector (PIR) is
installed in front of the door or in close proximity; the Camera or Motion Detector should be
configured as a Walk-Through device.
4.5.4.3. Chime
This feature provides audible warning for a door being opened when the system is disarmed.
Notes: This feature may be enabled for Magnetic Sensor (MGL) only, and is
possible only when a Siren is installed as well.
Configuring a Magnetic Sensor as Chime with no Siren installed is feasible,
but will have no functional value in the system.
A Magnetic Sensor may be defined as Entry/Exit or Walk-Through and as
Chime simultaneously.
