EverGuard-Care™ PERS System – Control Panel ES6502HC Installation, Operation and User Guide ESUG05026 Version 2.
Legal Notice Usage of this document, and all information (including product information) provided within, are subject to the following terms and conditions, and all applicable laws. If you do not agree with these terms, please do not access or use the remainder of this document. This document contains highly confidential information, which is proprietary to Essence Security International (E.S.I.) Ltd. and/or its affiliates (hereafter, "Essence").
For more information, please contact: Essence Security International (E.S.I.) Ltd. 12 Abba Eban Avenue, Ackerstein Towers Bldg. D Herzliya Pituach, 4612001 Israel www.essence-grp.
Table of Contents 1. Product Description ............................................................................................................ 1 1.1. Features ................................................................................................................................................2 1.2. Monitoring Activities ..........................................................................................................................2 2. Operation Summary .........................
3.2. Emergency ........................................................................................................................................ 15 3.3. Activity Timer .................................................................................................................................... 15 3.4. Speakerphone.................................................................................................................................. 16 3.5. Trouble Conditions ..........................
ADDENDUM A – PRIVACY POLICY................................................................................................... 42 Information Collection ........................................................................................................................... 43 Personally Identifiable Information ....................................................................................... 43 Non-Personally Identifiable Information .................................................................
1. Product Description The EverGuard-Care™ system is designed to provide on-demand emergency assistance in a safe and discreet manner. The heart of this system is the EverGuard-Care™ Control Panel (CP), which is an immediate response, control device designed for personal emergency applications. This manual describes the installation and operation of the EverGuard-Care™ Control Panel (CP) and should be given to the homeowner.
1.1. Features The EverGuard-Care™ Control Panel has the following features for ease of operation: The EMERGENCY and RESET buttons on the Control Panel are molded with Braille characters for ease of recognition by visually impaired users A built-in high volume speaker plus a very sensitive microphone Support for both half and full duplex conversation modes.
Alarm, which is reported to the Monitoring Station. Inactivity Timer If no activity from the Control Panel or any of the peripherals is detected within a preprogrammed period, the Control Panel generates an Inactivity Alarm, which is reported to the Monitoring Station. This is an additional layer of assurance provided by the system that can monitor user activity within the premises utilizing its peripherals.
Figure 1 – The EverGuard-Care™ System PERS Temp 4
2. Operation Summary The EverGuard-Care™ Control Panel can communicate with up to 64 wireless alarm triggering peripherals. The peripherals have the following functions: 2.1. Emergency The emergency peripherals are panic buttons that come in two types, a portable version (ES700EP) and a fixed version (ES700SPB). The portable version is completely waterproof and may be carried as a pendant or strapped on the wrist.
2.4.
Figure 2 – The EverGuard-Care™ Front Panel Type Symbol Power Display Meaning Type ON AC power Trouble connected Symbol Display Meaning ON Control Panel Red or peripheral malfunction Green Communicatio Blinking Battery operation OFF No power ON Communication Activity available Timer or Active Pairing n Green Blinking Blinking lost Red Blue ON Timer is ON OFF Timer is OFF Blinking Timer expires (ring) transmission ON Supervision Phone line failure or disconnected
Type Symbol Display Orange Sec) Meaning Type Symbol Display Meaning Red Blinking Unacknowledg ed pressed button OFF Idle Table 1 – The EverGuard-Care™ Front Panel Indicators 2.5. Removing the Bottom Cover To expose the Back Panel of the Control Panel, pull the tab while pressing from the inner part (power switch cavity) and remove the Bottom Cover.
2.6. Bottom Panel Features 5VDC/2A Plug-In Power Power Switch 3.7VDC/1.4A/Hour Backup Battery Test Button and Mini-USB connector (serial) for Local Programming SIM-card and Socket Figure 4 – The Back Panel 2.7. Installing the SIM-Card Remove the bottom cover of the Control Panel. The backup battery is exposed as well as the place to install a SIM-card for Control Panels that use wireless. Insert the SIM-card, with its contacts face down, as illustrated in Figure 5 below.
Note: Refer to the graphic representation of the SIM-card engraved onto the plastic bottom of the cavity, next to the socket, for accurate installation. Figure 5: Insertion of the SIM-card 2.8.
Figure 6 – Insert Battery The battery’s contacts should point towards the center of the Control Panel and face down as shown in Figure 6. 2.9.
2.10. Securing the Power Adapter Cube WARNING! Power switch must be turned OFF prior to the installation of the Backup Battery and the Power Adapter Secure the bracket with a screw for Power Adapter Secure the bracket with a screw for decorative style outlets Figure 8 – Securing the Power Adapter Cube Note: The Bracket must be installed to maintain UL Home Healthcare (UL 1637) Listing.
Two standard phone sockets (RJ-11) are provided on the rear panel of the PSTN model: Figure 9 – The Telephone Sockets Connect a telephone set to the socket marked PHONE Connect a telephone cable between the LINE socket and your home telephone outlet Once the telephone cable is connected to a functional telephone outlet, the Communication Indicator color should switch from red to green. Note: In the Cellular model, these PSTN telephone sockets are covered by a plastic hood. 2.12.
If the peripheral is already paired, the Control Panel beeps and the ring alternates with a blue and red light. If no additional peripheral can be integrated (full memory), the Control Panel beeps and the ring light red. The Control Panel returns to its previous operation mode automatically following the pairing process. 2.13.
3. System Operation 3.1. Standby Status Power Indicator lights steady green Communication Indicator lights steady green Activity Timer Indicator (ring around the EMERGENCY button) may be either ON or OFF 3.2. Emergency Press the EMERGENCY button and hold for a short duration or press the Emergency Button on either the portable or fixed device.
If no activity is detected (timeout), the Control Panel generates a report to the Monitoring Station. 3.4. Speakerphone Note: This feature may be disabled locally or remotely by the Monitoring Station. The Speakerphone mode can only be used for incoming calls and does not function if the Control Panel is running on backup battery. Attempting to answer a call while on battery generates an Emergency Alarm.
3.6.
This page was intentionally left blank PERS Temp 18
Appendix A Technical Specifications Item Data Weight 1.23lb (0.56Kg), including adapter and battery Dimensions 6 x 6 x 2.8in (152.4 x 152.4 x 71.12mm) Mains Power 100-240VAC, 50/60Hz, 500mA Reporting Mode SIA to standard receivers (V.90 for Monitoring Station configuration) Frequency 868.3 MHz in Europe and FM 916.5 MHz in America (Factory configured) Communication Channels Two different models: PSTN or cellular Color White and Grey Backup Battery 24 hours backup Battery Type Li-Po, 3.
This page was intentionally left blank PERS Temp 20
Terms, Abbreviations and Acronyms Term 3G Description 3G is a short for 3rd Generation. This is a term used to represent the 3rd generation of mobile telecommunications technology. Also called Tri-Band 3G. This is a set of standards used for mobile devices and mobile telecommunication services and networks that comply with the International Mobile Telecommunications-2000 (IMT2000) specifications issued and maintained by the International Telecommunication Union. AES Advanced Encryption Standard.
Term Description DC Direct Current DNS Domain Name System. A hierarchical distributed naming system for computers, services, or any resource connected to the Internet or a private network. It associates different types of information with domain names assigned to each of the participating entities. A Domain Name Service resolves queries for these names into IP addresses for the purpose of locating computer services and devices worldwide. ECOP An Essence Term. Enhanced Controlled Open Protocol.
Term GPRS Description General Packet Radio Service. A packet oriented mobile data service on the 2G and 3G cellular communication system's global system for mobile communications (GSM). GSM Global System for Mobile Communications. A standard set developed by the European Telecommunications Standards Institute (ETSI). The GSM standard describes protocols developed for second generation (2G) digital cellular networks which are used by mobile phones. HTTP Hypertext Transfer Protocol.
Term OS Description Operating system. A collection of software that manages computer hardware resources and provides common services for computer programs. PIR An Essence Term. A We.R™ system Motion Detector peripheral device. RF Radio Frequency. A rate of oscillation in the range of about 3 kHz to 300 GHz. This range corresponds to the frequency of radio waves, and the alternating currents which carry radio signals. RFID Radio-Frequency Identification.
Term SOAP Description Simple Object Access Protocol. A protocol specification created for exchanging structured information in the implementation of Web Services in computer networks. It relies on XML for its message format. It usually relies on other Application Layer protocols, most notably HTTP and Simple Mail Transfer Protocol (SMTP), for message negotiation and transmission. SSL Secure Sockets Layer. A cryptographic protocol that provide communication security over the Internet.
Term USB™ Description Universal Serial Bus. An industry standard defining the cables, connectors and communications protocols used in a bus for connection, communication and power supply between computers and electronic devices. WCF Windows Communication Foundation. A framework for building service-oriented applications. WWW, Web World Wide Web. Also abbreviated as WWW or W3 and known as the Web. A system of interlinked hypertext documents accessed via the Internet.
This page was intentionally left blank PERS Temp 27
Appendix B Additional Information B.1 FCC Part 68 Compliance The required customer information is provided in the Installation and Operation Guide. This equipment, EverGuard-Care, model ES6502HC, complies with Part 68 of the FCC Rules and the requirements adopted by the ACTA. On the rear side of this equipment is a label, that contains among other information, a product identifier in the format US:85IMM00BES6502HCP. If requested, this number must be provided to the telephone company. 1.
FCC Part 15 Compliance B.2 This device complies with FCC Rules Part 15 standard(s). Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation NOTES: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
