User's Manual

5.
Electrical Characteristics
5.5 Wi-Fi RF Characteristics
5.5.1 Wi-Fi RF Standards
Table 9: Wi-Fi RF Standards
Name Description
Center frequency range of operating channel
note1
2412 ~ 2462 MHz
Wi-Fi wireless standard IEEE 802.11b/g/n
Data rate
20 MHz
11b: 1, 2, 5.5 and 11 Mbps
11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
11n: MCS0-7, 72.2 Mbps (Max)
40 MHz 11n: MCS0-7, 150 Mbps (Max)
Antenna type PCB antenna, IPEX antenna
1. Device should operate in the center frequency range allocated by regional regulatory authorities. Target center frequency
range is configurable by software.
2. For the modules that use IPEX antennas, the output impedance is 50 Ω. For other modules without IPEX antennas,
users do not need to concern about the output impedance.
5.5.2 Transmitter Characteristics
Table 10: Transmitter Characteristics
Parameter
Rate
Unit
TX Power
note1
dBm
1. Target TX power is configurable based on device or certification requirements.
5.5.3 Receiver Characteristics
Table 11: Receiver Characteristics
Parameter Rate Typ Unit
RX Sensitivity
1 Mbps –97
dBm
2 Mbps –95
5.5 Mbps –93
11 Mbps –88
6 Mbps –92
Espressif Systems
10
Submit Documentation Feedback
ESP32-S2-WROOM & ESP32-S2-WROOM-I User Manual V0.5
802.11b:22.31dBm
802.11g:25.00dBm
802.11n20:24.23dBm
802.11n40:22.86dBm
