Manual

10
OM6100
OP E R AT ION
NOTE : Illus trations begin on page 3.
K now Your S now Thrower
(F igure 5)
R ead this Instruction Book and safety rules be-
fore operating the snow thrower. C ompare the
illustration with your s now thrower to familiarize
yourself with the location of various controls and
adjustments.
C rank As s embly (2)- C hanges the direction of
the discharge chute.
C hute Deflector (3)-
C hanges the distance the
snow is thrown.
Dis charge C hute (4)-
C hanges the direction the
snow is thrown.
Auger Drive L ever (5)-
S tarts and stops
the auger
which propels the snow thrower
.
Ignition K ey (8) -
Must be
inserted and turned
to the
on position to start the engine.
R ecoil S tarter Handle(12)-
Use to manually
start the engine.
C hoke C ontrol(14)- Use to start a cold engine.
How T o C ontrol
The Dis charge Of T he S now
WAR NING : Never direct the dis -
charge of s now toward bys tanders .
WAR NING : A lways s top the engine
before unclogging the dis c harge
chute or the auger hous ing and
before leaving the s now thrower.
1. (Figure 5)
Turn the
crank as s embly (2) to
change the discharge direction of the snow.
2. (Figure 6) Loosen the wing knob (1) on the
chute deflector (2).
3. Move the chute deflec tor (2) up for more
distance or down for less distance.
4. Tighten the wing knob (1).
How T o Throw S now
(F igure 5)
1. E ngage the auger drive lever (5).
2. To stop throwing snow, release the auger
drive lever (5).
WAR NING : T he operation of any
s now thrower c an res ult in
foreign objects being thrown
into the eyes , which can res ult in
s evere eye damage.A lways wear s afety
glas s es or eye s hields while operating
the s now thrower .We recommend
s tandard s afety glas s es or us e a wide
vis ion s afety mas k over your glas s es .
How To S top Dis charging S now
(Figure 5)
1. To stop discharging snow, release the auger
drive lever (5).
2. To stop the engine, turn the ignition key (8)
to the off position.
How To
Move F orward
(F igure 7)
1. Hold the auger drive lever (5)
against the
handle (2). T he auger will begin rotating.
2. To go forward, raise the handle (2)
to allow
the rubber auger blades (1)
to contact the
ground. Maintain a firm hold on the handle
(2) as the s now thrower s tarts to move for-
ward. G uide the snow thrower by moving the
handle (2) either left or right. Do not attempt
to push the snow thrower with eccessive force.
3. To stop, release the auger drive lever (5).
NOTE : If the auger continues to rotate,
s ee “ How To
A djus t The A uger C ontrol
C able” in the S ervice and A djus tments
s ec tion.
B efore S tarting The E ngine
1. Before you service or start the engine, famil-
iarize yourself with the s now thrower. B e
sure you understand the function and loca-
tion of all controls.
2. Make sure that all fasteners are tight.
3. Make sure the fuel tank is filled with the cor-
rect gasoline .
5.
Become familiar with the location of all con-
trols and understand their function.
6.
Before starting the engine, make sure all
controls operate correctly
.
Add The F uel Mixture
WAR NING : F ollow the engine
manufacturer’s ins truc tions for the
type of fuel and oil to us e. Always
us e a s afety fuel container. Do not s moke
when adding fuel to the engine. When
ins ide an enclos ure, do not fill the fuel
tank. B efore you add fuel,s top the engine.
L et the engine c ool for s everal minutes .
(Figure 7) Fill the fuel tank (3)
to the full posi-
tion with fresh, clean fuel.
How T o S top The E ngine
(F igure 5)
To stop the engine, turn the ignition key (8)
to
the off position. Keep the ignition key (8)
in a
safe place. T he engine will not start without the
ignition key (8).
How T o S tart A C old E ngine
(F igure 5)
1. Fill the fuel tank with a fresh, clean fuel
2.
Make sure the
auger drive lever (5)
is in the disengaged (released) position.
3. Insert the ignition key (8) and turn to the on
position.
4. Move the choke control (14)
to the C HOKE
position.
5. (R ecoil S tart) R apidly pull the
recoil s tarter
handle (12). Do not allow the recoil s tarter
handle (12) to snap back. S lowly return the
recoil s tarter handle (12).
6. If the engine does not start in 5 or 6 tries,
S ee the “Trouble S hooting C hart” Instruc-
tions.
7.
When the engine runs smoothly move the
choke c ontrol (14)
to the R UN
position.
4. Make sure the engine crank case is filled with
the correct amount and type of motor oil.
