User manual
Table Of Contents
- 1. Introduction
- 2. Technical data
- 3. For your safety
- 4. Transport, storage and disposal
- 5. Commissioning
- 6. Functional description
- 6.1 Operation
- 6.2 The Work mode
- 6.3 Parameter mode
- 6.4 Configuration mode
- 6.5 Factory settings (“default”)
- 6.6 Contrast
- 6.7 Replacing the soldering tip
- 6.8 Changing the Heating Element
- 6.9 Sensitive components
- 7. Error diagnosis and remedy
- 8. Maintenance
- 9. Replacement parts
- 10. Warranty
i-CON 1 / 7
3BA00180 • 28.04.2008 • Rev. 1
Operating instructions
3.1 Pictograph and symbol explanations
In this instruction manual, pictographs are used as hazard notes.
Special information or orders and prohibitions to prevent personal in-
jury or extensive material damage are supplemented by a pictograph
and in the text with hierarchically structured bold words:
Warning! Is used to warn of an imminent danger. Possible conse-
quences can be death or personal injury.
Attention! Is used to warn of a possible dangerous situation. The
consequences can be personal injury, material or environmental dam-
age.
Caution! Is used for an application recommendation. The conse-
quences of non-observance can be material damage.
In addition to the hierarchic warning notices described above, we use
the following symbols:
This is used to mark text passages which contain explanations, infor-
mation or tips.
■
This sign is used to mark
- activities which you must carry out, or
- instructions which must be followed by all means
