User manual
Table Of Contents
- 1. Introduction
- 2. Technical data
- 3. For your safety
- 4. Transport, storage and disposal
- 5. Commissioning
- 6. Functional description
- 6.1 Operation
- 6.2 The Work mode
- 6.3 Parameter mode
- 6.4 Configuration mode
- 6.5 Factory settings (“default”)
- 6.6 Contrast
- 6.7 Replacing the soldering tip
- 6.8 Changing the Heating Element
- 6.9 Sensitive components
- 7. Error diagnosis and remedy
- 8. Maintenance
- 9. Replacement parts
- 10. Warranty
i-CON 1 / 5
3BA00180 • 28.04.2008 • Rev. 1
Operating instructions
2. Technical data
Soldering station i-CON 1
Description Value Unit
Mains voltage 220-240 VAC
Mains frequency 50-60 Hz
Fuse (slow-blow) 0,8 A
Mains voltage 110-120 VAC
Mains frequency 50-60 Hz
Fuse (slow-blow) 1,6 A
Secondary voltage 24 VAC
Maximum short-term heating power 150 W
Mean heating power 80 W
Safety class I -
Permissable ambient temperature 0-40 °C
Temperature range (stepless) 150-450 °C
300-842
°F
Temperature regulation (at idle) < ± 2 °C
Ohmic resistance between soldering tip and ground < 2 Ohm
Soldering tip to ground leakage voltage < 2 mV eff
Other
Control technology SENSOTRONIC (PID-behaviour)
Function display LC-Display, blue
Supply line 2m, PVC, with connector
Single-knob control via incremental encoder (i-OP)
Antistatic surface, especially suited for the application in ESD areas. Option: Serial interface to control the
soldering smoke extractor EA110.
In accordance with MIL-SPEC/ESA-standard
VDE*, EMV-tested
Conformity
Connectable soldering tool: i-Tool
*A public safety testing company located in Germany.
Similar in operation to its United States counterpart, UL.
