Operating instructions
Replacement parts
Descriptiont Order-no.
Knurled nut for i-Tips 3N 497
Collar for i-Tips 3N 539
Knurled nut with jointing sleeve for i-Tips 3IT1040-00
Heating element for i-Tool 010102J
Viscose sponge for holder 0003B
Brass brush 3ZT00051
Drying sponge 0008M
